酵母真空转鼓过滤机

酵母真空转鼓过滤机

发布时间:2017/11/02 点击量:

一、酵母真空转鼓过滤机简介
酵母真空转鼓过滤机是我公司在不断总结客户单位使用的宝贵经验基础上持续完善,吸收国外的先进技术,结合我公司生产的淀粉真空转鼓过滤机的合理结构,自主研制开发的酵母专用JM型真空转鼓过滤机,本机连续运转、自动操作、过滤速度快、滤液澄清度高、运转可靠、维修方便,式一种理想的酵母液脱水设备,可替代国外同类进口设备。
JM type yeast vacuum drum filter is our continuous improvement in the basis of summing up the precious experience of customer units on the use of foreign advanced technology, combined with the reasonable structure of starch vacuum drum filter produced by our company, independently developed JM type special yeast vacuum drum filter development, the machine continuous operation, automatic operation, filtering speed fast, high filtrate clarity, reliable operation, convenient maintenance, is a kind of ideal yeast liquid dehydration equipment, can replace the similar foreign imported equipment.
酵母过滤机
二、工作原理
酵母真空转鼓过滤机工作原理与一般真空转鼓过滤机基本相同,主要区别在于转鼓无格室,滤室不分腔,过滤前必须进行过滤介质(如马铃薯淀粉)的预涂,由预涂层和不锈钢滤布共同完成过滤。在真空抽吸作用下,转鼓外表面逐渐吸上所需要的预涂层厚度,然后注入被过滤的酵母液,在真空抽下作用下,开始过滤。液体被吸入转鼓内通道被抽走,悬浮液中的酵母被吸附在预涂层表面,机械刮刀自动进给,不断刮去酵母滤饼,距转鼓表面5-6mm时,刮刀自动停止进给,然后退刀,重新预涂,进入下一个工作循环。
JM type yeast vacuum drum filter working principle and general vacuum drum filter is basically the same, the main difference is that no drum chamber, the filter chamber or cavity, must be filtered before filtration medium (such as potato starch) pre coated, by pre coating and stainless steel filter cloth together. Under vacuum suction, the outer surface of the drum gradually absorbed the required pre coating thickness, and then injected the filtered yeast fluid, and began to filter under the vacuum pumping. The liquid is sucked into the drum inside the channel is pumped out, the suspension of yeast is adsorbed on the surface of pre coating, mechanical automatic feed scraper, constantly scraping the yeast cake, from the drum surface 5-6mm, automatic stop feed scraper, and then retracting, re pre coated, in a working cycle.

三、应用领域
食用酵母的脱水过滤、酿造业酵母、饲料酵母以及其他酵母的脱水过滤
Dehydration and filtration of edible yeast, dehydration and filtration of brewing yeast, feed yeast and other yeasts
酵母过滤机
四、产品特点
1.个性化的设计,满足不同客户需求
Personalized design to meet the needs of different customers
2.整体抛光处理,达到食品级要求
The overall polishing process meets the requirements of food grade
3.鼓面整体加工,精益求精
Drum whole processing, excellence
4.自动刮刀控制,操作简单方便
Automatic scraper control, easy to operate
5.采用平面接触式分配阀,密封性好,下料干度高
The plane contact type distributing valve has good sealing performance and high drying quality
6.采用预涂技术,滤液澄清度高
By using precoating technology, the clarification of filtrate is high
7.生产环境优,经济效益好
The production environment is excellent and the economic benefit is good
